Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212

Model Number : TD1010

MOQ : 1000

Delivery Time : 14-21days

Payment Terms : T/T L/C

Price : 0.58

Certification : ISO9001:2015; RoHS; REACH

Supply Ability : 100000pcs

Brand Name : Careful Tenda

Place of Origin : Guangdong, China

Contact Now

Careful Tenda Vertical Essential Common Mode Inductor TD1212
The Careful Tenda TD1212 Common Mode Inductor features an anti-saturation toroidal core and pure copper flat wire winding, delivering reduced AC resistance and temperature rise while providing reinforced insulation for superior voltage withstand. Its vertical orientation optimizes board space and simplifies PCB layout.
ISO9001-manufactured and fully RoHS/REACH compliant, the TD1212 provides reliable, certified EMI suppression in a space-saving design.
Key Features
  • High-performance anti-saturation toroidal core
  • Pure copper flat wire construction
  • Minimized AC resistance and temperature rise
  • Reinforced insulation for superior voltage withstand
  • Industry-standard 10×13 mm pin footprint
  • Space-saving compact vertical design
Technical Specifications
Type Common mode choke
Function EMI/EMC Suppression
Model Number TD1212
Brand Name Careful Tenda
Application EMI/EMC Suppression
Place of Origin Guangdong, China
Inductance 15mH Min
Size / Dimension 18.5×12×18.5mm
Height 21.5mm
Number of Coils 52
Material - Core R12K
DC Resistance (DCR) 240mΩ Max
Product Images
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
Careful Tenda Vertical Essential Common Mode Inductor with Core Reliability TD1212
